Addr. Parameter C Setting Options Default Setting Comments
0 MEAS. QUANTITY Please select
Current
Voltage
Voltage Side2
P forward
P reverse
Q forward
Q reverse
Power factor
Frequency
df/dt rising
df/dt falling
Binary Input
Please select Selection of Measured
Quantity
0 MEAS. METHOD Fundamental
True RMS
Positive seq.
Negative seq.
Zero sequence
Ratio I2/I1
Delta value
Fundamental Selection of Measurement
Method
0 PICKUP WITH Exceeding
Dropping below
Exceeding Pickup with
0 CURRENT Ia
Ib
Ic
In
In sensitive
Ia Current
0 VOLTAGE Please select
Van
Vbn
Vcn
Vab
Vbc
Vca
Vn
Please select Voltage
0 VOLTAGE Please select
V2an
V2bn
V2cn
V2a2b
V2b2c
V2c2a
V2n
Please select Voltage
0 POWER Ia Van
Ib Vbn
Ic Vcn
Ia Van Power
0 VOLTAGE SYSTEM Phase-Phase
Phase-Ground
Phase-Phase Voltage System
Functions
2.19 Flexible Protection Functions
