No. Information Type of
Informa-
tion
Comments
30706 Qc = MV Qc (reactive power, phase C)
30707 PFa = MV Power Factor, phase A
30708 PFb = MV Power Factor, phase B
30709 PFc = MV Power Factor, phase C
31249 V2a = MV V2a
31250 V2b = MV V2b
31251 V2c = MV V2c
31252 V2a-2b= MV V2a-2b
31253 V2b-2c= MV V2b-2c
31254 V2c-2a= MV V2c-2a
31255 VNS2 = MV VN Side2
31256 V1S2 = MV V1S2 (positive sequence Side2)
31257 V2S2 = MV V2S2 (negative sequence Side2)
31258 VoS2 = MV VoS2 (zero sequence Side2)
31259 FreqS2= MV Frequency Side2
31346 Phi Va = MV Angle Va
31347 Phi Vb = MV Angle Vb
31348 Phi Vc = MV Angle Vc
31349 Phi Va-b = MV Angle Vab
31350 Phi Vb-c = MV Angle Vbc
31351 Phi Vc-a = MV Angle Vca
31352 Phi VN = MV Angle VN
31353 Phi Vo = MV Angle Vo
31354 Phi V1 = MV Angle V1
31355 Phi V2 = MV Angle V2
31356 Phi Vx = MV Angle Vx
31357 Phi Ia = MV Angle Ia
31358 Phi Ib = MV Angle Ib
31359 Phi Ic = MV Angle Ic
31360 Phi In = MV Angle In
31361 Phi 3Io = MV Angle 3Io
31362 Phi I1 = MV Angle I1
31363 Phi I2 = MV Angle I2
31364 Phi V2a = MV Angle V2a
31365 Phi V2b = MV Angle V2b
31366 Phi V2c = MV Angle V2c
31367 Phi V2a-2b= MV Angle V2a-2b
31368 Phi V2b-2c= MV Angle V2b-2c
31369 Phi V2c-2a= MV Angle V2c-2a
31370 Phi VNS2 = MV Angle VNS2
31371 Phi VoS2 = MV Angle VoS2
31372 Phi V1S2 = MV Angle V1S2
31373 Phi V2S2 = MV Angle V2S2
31374 Phi INs = MV Angle INs
Functions
2.26 Auxiliary Functions
SIPROTEC Compact, 7SC80, Manual 375
E50417-G1140-C486-A8, Edition 07.2017
