Addr. Parameter Setting Options Default Setting Comments
172 52 B.WEAR MONIT Disabled
Ix-Method
2P-Method
I2t-Method
Disabled 52 Breaker Wear Monitoring
180 Fault Locator Disabled
Enabled
Disabled Fault Locator
181 L-sections FL 1 Section
2 Sections
3 Sections
1 Section Line sections for fault locator
182 74 Trip Ct Supv Disabled
2 Binary Inputs
1 Binary Input
Disabled 74TC Trip Circuit Supervision
350 Bat. Monitor Disabled
Enabled
Disabled Battery voltage Monitor
368 AssignMeasInput Ia, Ib, Ic, Vx
INs,Ib,Ic,Vx=Ia
Ia, INs, Ic, Vx
Ia, Ib, Ic, Vx Assignment measurement inputs
369 VT Con Type CONVENTIONAL
LoPo/LPS
Cap. Volt.Meas.
CONVENTIONAL Voltage connection type
370 27/59 Vx Enabled
Disabled
Disabled 27/59 Over/under volt. Prot. for Vx
371 Capacitor Ctrl. Disabled
Enabled
Disabled Capacitor Control
372 Tap Changer Disabled
Enabled
Disabled Tap Changer
374 Triple Single Disabled
Enabled
Disabled Triple Single Mode
375 Capacitor Test Disabled
Enabled
Disabled Recloser capacitor Test
376 Sectionalizer Disabled
With prot.
Without prot.
Disabled Sectionalizer Function
377 VT Con Type S2 CONVENTIONAL
LoPo/LPS
Cap. Volt.Meas.
CONVENTIONAL Voltage connection type Side2
Functions
2.1 General
