[hlt_control, 1, en_US]
Figure 2-130
Service Interlocking, Example of Internal Interlocking, External, and Binary Input
You can connect the signals and indications in the routing matrix as desired, for example to the LEDs of the
operation panel or for transmitting or receiving data over the system interface. The following figure shows an
example for routing the information.
[hlt_rangierung, 1, en_US]
Figure 2-131 Service Interlocking, Example for Routing to LEDs
The service interlocking indications are logged in the operational log.
Functions
2.27 Breaker Control
SIPROTEC Compact, 7SC80, Manual 393
E50417-G1140-C486-A8, Edition 07.2017
