Special Parameters in
Easy Setting GUI View
C Setting Options Default Setting Description
PTx Secondary Voltage 34 .. 230 V 100 V Set the PTx secondary
voltage value.
PT A Phase Angle
Correction
-90.00 .. 90.00 ° 0.00 ° Set the PT phase A
angle correction.
PT B Phase Angle
Correction
-90.00 .. 90.00 ° 0.00 ° Set the PT phase B
angle correction.
PT C Phase Angle
Correction
-90.00 .. 90.00 ° 0.00 ° Set the PT phase C
angle correction.
PT A Phase Angle
Correction Side2
-90.00 .. 90.00 ° 0.00 ° Set the PT phase A
angle correction
side 2.
PT B Phase Angle
Correction Side2
-90.00 .. 90.00 ° 0.00 ° Set the PT phase B
angle correction
side 2.
PT C Phase Angle
Correction Side2
-90.00 .. 90.00 ° 0.00 ° Set the PT phase C
angle correction
side 2.
PTx Phase Angle
Correction
-90.00 .. 90.00 ° 0.00 ° Set the PTx phase
angle correction.
PT A Correction Factor 0.5000 .. 2.0000 1.0000 Set the PT phase A
correction factor.
PT B Correction Factor 0.5000 .. 2.0000 1.0000 Set the PT phase B
correction factor.
PT C Correction Factor 0.5000 .. 2.0000 1.0000 Set the PT phase C
correction factor.
PT A Correction Factor
Side2
0.5000 .. 2.0000 1.0000 Set the PT phase A
correction factor
side 2.
PT B Correction Factor
Side2
0.5000 .. 2.0000 1.0000 Set the PT phase B
correction factor
side 2.
PT C Correction Factor
Side2
0.5000 .. 2.0000 1.0000 Set the PT phase C
correction factor
side 2.
PT x Correction Factor 0.5000 .. 2.0000 1.0000 Set the PTx correction
factor.
Functions
2.29 Recloser Setting Summary
