Operating modes of the clock management
Operating mode Comments
Internal Internal synchronization via RTC (default)
Pulse via binary input External synchronization with pulse via binary input
Field bus (DNP) External synchronization via field bus
NTP (IEC 61850) External synchronization using port F (IEC 61850)
GPS External synchronization via GPS
IRIG-B External synchronization via IRIG-B
Setting Group Change Option of the Functional Settings
Number of available setting groups 16 (parameter group A to P)
The change can be performed via HMI at the device
DIGSI via user interface
Protocol using port F
Binary input
IEC 61850 GOOSE (inter-device communication)
The GOOSE communication service of IEC 61850 is qualified for switchgear interlocking. Since the transmis-
sion time of GOOSE messages depends on both the number of IEC 61850 clients and the pickup condition of
the device, GOOSE is not generally qualified for protection-relevant applications. The protection application
must be checked with regard to the required transmission times and coordinated with the manufacturer.
Technical Data
4.23 Additional Functions
SIPROTEC Compact, 7SC80, Manual 575
E50417-G1140-C486-A8, Edition 07.2017
