Siemens 7SC80 - Page 58

Addr. Parameter C Setting Options Default Setting Comments
214 Rated Frequency 50 Hz
60 Hz
16,7 Hz
50 Hz Rated Frequency
215 Distance Unit km
Miles
km Distance measurement
unit
217 Ignd-CT PRIM 1 .. 50000 A 60 A Ignd-CT rated primary
current
218 Ignd-CT SEC 1A
5A
1A Ignd-CT rated secondary
current
219 VT Con. 3ph S2 V2an,V2bn,V2cn
V2a2b,V2b2c,VGn
V2a2b, V2b2c
V2an,V2bn,V2cn VT Connection, three
phase Side2
220 Vnom prim S2 0.10 .. 800.00 kV 20.00 kV Rated Primary Voltage
Side2
221 Vnom sec S2 34 .. 225 V 100 V Rated Secondary Voltage
(L-L) Side2
222A Vph/Vdelta S2 1.00 .. 3.00 1.73 Matching ratio Vph To
Vdelta Side2
235A ATEX100 NO
YES
YES Storage of th. Replicas w/o
Power Supply
241 Volt.trans.A:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer A:
Capacity C1
242 Volt.trans.A:C2 250 .. 10000 pF 2200 pF Voltage transducer A:
Capacity C2
243 Volt.trans.B:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer B:
Capacity C1
244 Volt.trans.B:C2 250 .. 10000 pF 2200 pF Voltage transducer B:
Capacity C2
245 Volt.trans.C:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer C:
Capacity C1
246 Volt.trans.C:C2 250 .. 10000 pF 2200 pF Voltage transducer C:
Capacity C2
247 Volt.tran.Vx:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer Vx:
Capacity C1
248 Volt.tran.Vx:C2 250 .. 10000 pF 2200 pF Voltage transducer Vx:
Capacity C2
250A 50/51 2-ph prot OFF
ON
OFF 50, 51 Time Overcurrent
with 2ph. prot.
251 Volt.tran.2A:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer 2A:
Capacity C1
252 Volt.tran.2A:C2 250 .. 10000 pF 2200 pF Voltage transducer 2A:
Capacity C2
253 Volt.tran.2B:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer 2B:
Capacity C1
254 Volt.tran.2B:C2 250 .. 10000 pF 2200 pF Voltage transducer 2B:
Capacity C2
255 Volt.tran.2C:C1 1.0 .. 100.0 pF 10.0 pF Voltage transducer 2C:
Capacity C1
256 Volt.tran.2C:C2 250 .. 10000 pF 2200 pF Voltage transducer 2C:
Capacity C2
Functions
2.1 General
