Addr. Parameter C Setting Options Default Setting Comments
338A VT Ph. Connect. A B C
B C A
C A B
A C B
B A C
C B A
A B C VT Phase terminal connec-
tion
339A INs LPS AmplCor 0.5000 .. 2.0000 1.0000 CT ampl. correction factor
INs LoPo/LPS
340A CT A AMPL COR 0.5000 .. 2.0000 1.0000 CT amplitude correction
factor A
341A CT B AMPL COR 0.5000 .. 2.0000 1.0000 CT amplitude correction
factor B
342A CT C AMPL COR 0.5000 .. 2.0000 1.0000 CT amplitude correction
factor C
343A IGND AMPL COR 0.5000 .. 2.0000 1.0000 CT amplitude correction
factor IGND
344A VT PhAng COR A -90.00 .. 90.00 ° 0.00 ° VT phase angle correction
A
345A VT Vx PhAng COR -90.00 .. 90.00 ° 0.00 ° VT phase angle correction
Vx
346A VT A AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor A
347A VT B AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor B
348A VT C AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor C
349A Vx AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor Vx
357A VT PhAng COR B -90.00 .. 90.00 ° 0.00 ° VT phase angle Correction
B
358A VT PhAng COR C -90.00 .. 90.00 ° 0.00 ° VT phase angle Correction
C
359A VT PhAng COR 2A -90.00 .. 90.00 ° 0.00 ° VT phase angle correction
2A
360A VT PhAng COR 2B -90.00 .. 90.00 ° 0.00 ° VT phase angle correction
2B
361A VT PhAng COR 2C -90.00 .. 90.00 ° 0.00 ° VT phase angle correction
2C
362A VT 2A AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor 2A
363A VT 2B AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor 2B
364A VT 2C AMPL COR 0.5000 .. 2.0000 1.0000 VT amplitude correction
factor 2C
365A VT Ph. Con. S2 A B C
B C A
C A B
A C B
B A C
C B A
A B C VT Phase terminal connec-
tion Side2
Functions
2.1 General
