No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
680 Angle Va-Ia (Phi A =) Measurement - - - - - CFC CD
681 Angle Vb-Ib (Phi B =) Measurement - - - - - CFC CD
682 Angle Vc-Ic (Phi C =) Measurement - - - - - CFC CD
701 Resistive ground current in isol
systems (INs Real)
Measurement 134 157 No 9 15 CFC CD
702 Reactive ground current in isol
systems (INs Reac)
Measurement 134 157 No 9 16 CFC CD
807 Thermal Overload (Θ/Θtrip) Measurement - - - - - CFC CD
830 INs Senstive Ground Fault Current
(INs =)
Measurement 134 118 No 9 3 CFC CD
134 158 No 9 1
831 3Io (zero sequence) (3Io =) Measurement - - - - - CFC CD
832 Vo (zero sequence) (Vo =) Measurement 134 118 No 9 2 CFC CD
833 I1 (positive sequence) Demand (I1
dmd=)
Demand meter - - - - - CFC CD
834 Active Power Demand (P dmd =) Demand meter - - - - - CFC CD
835 Reactive Power Demand (Q dmd
=)
Demand meter - - - - - CFC CD
836 Apparent Power Demand (S dmd
=)
Demand meter - - - - - CFC CD
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CFC CD
838 I A Demand Maximum
(IAdmdMax)
Min/Max meter - - - - - CFC CD
839 I B Demand Minimum (IBdmdMin) Min/Max meter - - - - - CFC CD
840 I B Demand Maximum
(IBdmdMax)
Min/Max meter - - - - - CFC CD
841 I C Demand Minimum (ICdmdMin) Min/Max meter - - - - - CFC CD
842 I C Demand Maximum
(ICdmdMax)
Min/Max meter - - - - - CFC CD
843 I1 (positive sequence) Demand
Minimum (I1dmdMin)
Min/Max meter - - - - - CFC CD
844 I1 (positive sequence) Demand
Maximum (I1dmdMax)
Min/Max meter - - - - - CFC CD
845 Active Power Demand Minimum
(PdMin=)
Min/Max meter - - - - - CFC CD
846 Active Power Demand Maximum
(PdMax=)
Min/Max meter - - - - - CFC CD
847 Reactive Power Minimum
(QdMin=)
Min/Max meter - - - - - CFC CD
848 Reactive Power Maximum
(QdMax=)
Min/Max meter - - - - - CFC CD
849 Apparent Power Minimum
(SdMin=)
Min/Max meter - - - - - CFC CD
