9
Messages, Service Displays, PLC Data – Operating Area Diagnosis 03.04
9.4 Service dis
la
s
9
9.4.1 Service axes
Precondition
• The Serv. axis softkey has been pressed in the Service Displays
working window.
Service Axes working window
Operating sequence
• Use the cursor keys to select the desired line.
Further buttons
Axis -/+ Displays information about the previous/next axis
Recall → Returns to the Service Displays working window.
Siemens AG, 2004. All rights reserved.
9-106 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
