Machine Data, NC Start-Up, System Parameters – Operating Area Start-Up 03.04
10.4 PLC
10
10.4 PLC
These functions are described in Section 9, Subsection "PLC".
10.5 HMI startup
Function
The following individual settings are available on the HMI:
• Language selection
• Action log
• DOS editor
Precondition
The HMI softkey in the Startup working window has been pressed.
The following working window is then displayed:
NC Startup Overview working window
Operating sequence
You can call the following functions with the corresponding softkey:
Lang. Selec. → Language Selection working window (SK only
appears if more than two languages are loaded)
Action log → Action Log working window
DOS editor → DOS Editor working window
Siemens AG, 2004. All rights reserved.
10-126 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
