3
03.04 Parameters operating area
3.6 User data
3
3.6 User data
3.6.1 Overview
Function
User data (Global User Data, GUD) can be used to globally define
certain states for a machine, e.g. the return plane or the clearance
distance.
The user data are stored in the directory "/_N_DEF_DIR".
References
More information on the subject of "User data" can be found in
/BA/ SINUMERIK Operating Instructions, User Data and
/PGA/ SINUMERIK Programming Guide, Job Planning
The following user data can be displayed and modified:
• global
• channel-specific
• local
• program-global
Precondition
• The User data softkey has been pressed in the Parameters
Operating Area working window.
Operating sequence
• Use the softkey to select the desired type of user data.
Global Global User Data working window
Channel-spec. Channel-specific User Data working window
Local Local User Data working window
Program Program-global User Data working window
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 3-41
