5
03.04 Manual Mode – Operating Area Machine
5.4 Re
ositionin
5
5.4 Repositioning
Function
In the Jog operating mode the control saves the coordinates of the
interruption point. The path differences of the axes traversed in Jog
mode can be displayed.
After the interruption the displacement is reversed with the Jog keys
(i.e. the axis is repositioned).
Precondition
REPOS
• Control Panel Function key and
• REPOS softkey have been pressed.
Operating sequence
• Use the Jog key to traverse the desired axis by pressing
the + or - side.
The motion stops when the Repos value reaches zero.
Several axes can be traversed at the same time here as well.
5.5 Increment
Function
The increment is the step width by which the selected axis is
traversed each time the associated Jog key is pressed. It can also be
modified either via the keyboard or via a softkey.
Precondition
INC
• The Increment softkey has been pressed in the MCS Actual
Values /WCS Actual Values working window.
The following working window is then displayed:
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 5-65
