Messages, Service Displays, PLC Data – Operating Area Diagnosis 03.04
9.6 Remote dia
g
nosis
9
 Siemens AG, 2004. All rights reserved.
9-114 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
9.6 Remote diagnosis
Function
If no modem was active during startup then this function can be used
to manually start the remote diagnosis. The remote diagnosis can be
parameterized in the PowerOn startup menu (key 6 during startup)
(e.g. automatic starting of the remote diagnosis during startup). The
baud rate etc. are set using a third-party product, e.g. "Reach Out".
Precondition
Once the Remote diagn. softkey has been pressed in the Messages
working window, the Remote Diagnosis working window appears.
Operating sequence
• OK The remote diagnosis is started and a restart is
performed.
If the remote diagnosis has already been started the message
"Remote diagnosis has already been started" is output and the
working window is closed.
Further buttons
Recall Goes to the Messages working window without
starting the remote diagnosis.
References
Information about the installation and operation of the remote
diagnosis can be found in the following documentation:
/FBFE/ Description of Functions, Remote Diagnosis, FE1 (ReachOut)

