Siemens HT6

3
03.04 Parameters operating area
3.4 Settin
g
data
3
Further buttons
Channel -/+ Previous/next channel number
Search Search for a number or a (part of a) name
Continue
search Searches again for the same search string
Recall Returns to the Setting Data working window
3.4.3 Axis-specific setting data
Prerequisites
• The softkey Axis SD has been pressed in the Setting Data
working window.
The Axis-specific Setting Data working window opens.
All of the axis-specific setting data are listed.
Operating sequence
• Select the setting data with the cursor. (The machine data name
is displayed in the dialog line).
• Use the numerical input to modify the data.
• Press Input to accept the value (or exit the field to do this).
Further buttons
Axis -/+ Previous/next axis number
Search Search for a number or a (part of a) name
Continue
search Searches again for the same search string
Recall Returns to the Setting Data working window
 Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 3-37
