Data Transmission – Operating Area Services 03.04
8.2 Read in data
8
8.2.8 RS-232-C settings, special functions
Function
Expanded parameterizing functions can be found in the Special
Functions working window.
Precondition
• Part 2 softkey has been pressed in the working window RS-232-
C Settings.
The following working window is then displayed:
RS-232-C Settings, Special Functions working window
Operating sequence
• Use the cursor to select the desired line.
• Change the selected value with the SELECT key.
• Transfer the changes to the working memory using the Save
settings softkey.
Further buttons
Part 1 → RS-232-C Settings working window:
Parameters (1)
Save settings Save settings and return to calling working window.
Recall → Returns to starting window without accepting the
changes.
Siemens AG, 2004. All rights reserved.
8-100 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
