8
03.04 Data Transmission – Operating Area Services
8.2 Read in data
8
The following working window is then displayed:
RS-232-C Settings working window
Operating sequence
• Use the cursor to select the desired line.
• Change the upper six values with the SELECT key.
• Change the lower values alphanumerically, and if the special
functions (RS-232-C Settings working window, Special functions)
are not to be parameterized as well:
• Transfer the changes to the working memory using the Save
settings softkey.
Further buttons
Part 2 → RS-232-C Settings working window: Parameters
(2) Special functions
Save settings Save settings and return to calling window.
Recall → Returns to starting window without accepting the
changes.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 8-99
