Siemens HT6

8
03.04 Data Transmission – Operating Area Services
8.2 Read in data
8
Effect:
No field checked: First field checked: Second (or both)
field(s) checked:
The files are copied to
the directory selected
in the Read in Data
working window.
The files are copied to
the directory shown in
the header of the file.
Files are copied to the
clipboard.
• Start the transfer by clicking on the OK softkey.
The Transfer working window will then appear.
Further buttons
Cancel softkey or
Recall Returns to the starting window Read in Data
8.2.2 Transfer
Function
The current status of the file transfer is shown on the screen.
Precondition
• The Start softkey has been pressed in the Select Target
Directory working window.
The following message appears: "Transfer active"
The following are displayed:
− when reading in the data: only the number of transmitted bytes
− when outputting the data: the path and name of the last
transmitted file as well.
Further buttons
Softkey Stop or
Recall Transfer is aborted, screen returns to the calling
working window Read-in data.
 Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 8-95
