8
Data Transmission – Operating Area Services 03.04
8.2 Read in data
8
8.2.1 Selecting a target directory
Function
Files can be copied
• to the directory selected in the Read in Data working window, or
• to the directory shown in the header of the file, or
• to the clipboard.
Precondition
• The Start softkey has been pressed in the Read in data working
window.
The following working window is then displayed:
Select Target Directory working window
Operating sequence
• Use the cursor to select the desired target directory
("path/workpiece from archive file" and/or "read in to clipboard")
• Use the SELECT key to activate or deactivate the directory.
Siemens AG, 2004. All rights reserved.
8-94 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
