03.04 Messages, Service Displays, PLC Data – Operating Area Diagnosis
9.5 PLC
9
9.5.2 Date/time
Precondition
• The Date/time softkey in the PLC working window has been
pressed.
The following working window is then displayed:
Date and time working window (inverted softkey: currently active
function)
Operating sequence
• Use the cursor keys to move to the desired input field.
• Input the alphanumerical changes.
• Click on the OK softkey to accept the changes.
Further buttons
Manual sync. Synchronizes the PLC and HMI times.
autom. on The time after which synchronization is automatically
performed is entered in the "Synchronization time"
field.
autom. off No automatic synchronization ("Synchronization time"
line disappears).
Recall Goes to the PLC working window without accepting
the changes.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 9-113
