4
Program operating area 03.04
4.2 Editor in normal mode
4
Input New line after the cursor
Any changes and inputs are accepted whenever you leave a line.
4.2.2 Text search
Function
You can search for any sequence of characters (string) in the program
to be edited.
Prerequisites
The softkey Search has been pressed in the Editor in Normal Mode
working window.
The Text Search working window opens in the lower half of the
screen.
Operating sequence
• Enter the string you wish to search for in the Search line.
• Click on the OK softkey to confirm.
The editor searches for the entered string and jumps to the point
where it finds it.
Further buttons
Abort (Softkey) or
Recall Cancels the search and returns to the Editor in
Normal Mode working window.
Siemens AG, 2004. All rights reserved.
4-56 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
