Messages, Service Displays, PLC Data – Operating Area Diagnosis 03.04
9.4 Service dis
p
la
y
s
9
9.4.3 Communications log
Function
The following working window logs the communications between the
HMI and NCK/PLC. Date and time are output at the start of
communications.
Softkeys
Same as Service Displays working window.
9.4.4 Action log
Function
You can display an existing action log.
This function is only intended for service purposes.
Softkeys
Same as Service Displays working window.
Further buttons
Curr. data The displayed data are updated
Data RS-232-C Transfer of the data via RS-232-C
