4
Program operating area 03.04
4.1 Directories
4
Further buttons
Recall Standard Directories Overview working window
Input Workpiece Selection working window
4.1.2 Create new workpiece
Function
To create a new workpiece, a working window opens up requesting
the input of the workpiece name.
In this new, empty directory you can create files for the programs
which are required for machining of the workpiece.
Precondition
The softkey New has been selected in the working window Workpiece
Overview. An additional Create New Workpiece working window then
opens in the lower half of the screen.
Operating sequence
• Type in the new name.
The type has already been set by default to "workpiece" (WPD).
• Click on the softkey OK to create the workpiece directory.
In this empty directory you can create a new file and edit it.
Further buttons
Abort (Softkey) or
Recall Exits the working window without
creating a
workpiece
Siemens AG, 2004. All rights reserved.
4-48 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
