03.04 Machine Data, NC Start-Up, System Parameters – Operating Area Start-Up
10.2 Machine data
10
10.2.4 Drive configuration
Precondition
• The Drive Conf. softkey in the Machine Data Overview working
window has been pressed.
The following working window is then displayed:
Drive Configuration working window
Softkeys
As described in the section "General machine data".
10.2.5 Drive-specific machine data
Function
This function enables
• Changes to drive-specific machine data
• Calculation of controller data
• Saving/deleting of boot files
Precondition
The feed-specific machine data information is displayed from left to
right in the window which pops up.
See section "General machine data"
The selected machine data name is displayed in the dialog line.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 10-121
