10
Machine Data, NC Start-Up, System Parameters – Operating Area Start-Up 03.04
10.2 Machine data
10
10.2.2 Channel-specific machine data
Precondition
• The Channel MD softkey in the Machine Data Overview working
window has been pressed.
The channel-specific machine data information is displayed from left
to right in the window which pops up.
See section "General machine data"
Operating sequence
As described in the section "General machine data".
Further buttons
Channel -/+ Displays the previous/next channel
The remaining buttons are the same as the ones described in the
section "General machine data".
10.2.3 Axis-specific machine data
Precondition
• The Axis MD softkey in the Machine Data Overview working
window has been pressed.
The axis-specific machine data information is displayed from left to
right in the window which pops up.
See section "General machine data"
Operating sequence
As described in the section "General machine data".
Further buttons
Axis -/+ Displays the previous/next axis
The remaining buttons are the same as the ones described in the
section "General machine data".
Siemens AG, 2004. All rights reserved.
10-120 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
