7
03.04 Teach-In
7.4 Chan
in
a block
7
Operating sequence
• Select the desired parameter with the corresponding softkey or
• move the cursor to the previous/next input field,
• select or deselect the axis with the SELECT key and
• click on the OK softkey to accept the settings and return to the
starting window.
• Recall → Returns to the starting window without accepting the
settings
7.4 Changing a block
Function
To change a block which has already been programmed you proceed
in a similar way to the procedure for inserting a block,
• except that you press the Change softkey.
The block to be changed is displayed.
Operating sequence
With the Input button you can swap the programmed values in the
block for the actual values for the selected axes. The cursor is then
positioned at the start of the changed block.
Only the actual values are overwritten. It is not possible to insert new
axes or delete existing axes.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 7-87
