User interface 03.04
2.2 Dis
la
2
2.2.1 Status indicator
Structure
FieldñNo. 1. 2. 3. 4. 5. 6. 7. 8.
Ma Auto Teach MCS Trafo 100% ASY2 Chan10
Active PROG56789012345678 SBL1 NCName
(Reserved
for machine
tool manu-
facturers)
Field No. 9. 10. 11. 12. 13.
Explanations 1. Operating area identifier
Ma Machine
Pa Parameters
Pr Program
Di Services
Di Diagnostics
Ib Commissioning
Te Teaching
2. Operating mode (Auto, Jog, Mda)
3. Machine function (Teach, Ref, Repos)
4. JOG mode (MCS = Machine coordinate system, WCS =
Workpiece coordinate system)
5. Transformation activated (Trafo). Only appears when
Transformation is activated.
6. Override
7. Axis system on which the traversing keys act (ASY2, ASY3,
ASY4).
In the standard setting, an empty text is displayed for axis system
1 (traversing keys generally act on axes 1 – 6).
8. Channel name
9. Process status of the channel (active, stop, reset)
10. Name of the selected program (max. of 24 characters)
11. Single block mode (SBL1, SBL2). Only appears when Single
Block Mode is activated.
12. Name of the NC to which the channel is assigned
13. This area can be used by the machine manufacturer (refer to the
machine manufacturer’s details).
2.2.2 Alarm display
Line: Alarm text or program messages
1. Line: Alarm text or program messages (e.g. Stop: EMERGENCY
OFF active)
