Program operating area 03.04
4.1 Directories
4
4.1.5 Cycles
Function
Cycles are subroutines which are used to perform repetetive
machining processes on the workpiece.
Precondition
In the Standard Directories Overview working window one of the
following softkeys has been selected:
CST for the standard cycles or, analogously,
CUS for user cycles
CMA for manufacturer cycles.
The Cycles main screen contains a complete overview of all standard
cycles (CST) and, analogously, all user cycles (CUS) and
manufacturer cycles (CMA).
Operating sequence
The following softkeys are available:
New Creates a new cycle directory
Copy Copies the selected cycle to the clipboard
Paste Inserts a cycle which was previously copied to the
clipboard
Delete Deletes the selected cycle (after a safety prompt)
Rename Allows the currently selected cycle to be renamed
Enable The selected file receives/loses the enable identifier.
This is indicated with an "X"; the program can be
worked through
Selection Cycle Selection working window
Further buttons
Recall Standard Directories Overview working window
Input Cycle Selection working window
