3
Parameters operating area 03.04
3.1 Introduction
3
3.1 Introduction
Before you start working with the CNC, set up the machine, tools etc.
on the CNC:
• Input/change the tool data (tool offsets),
• Input/change the R parameters,
• Input/change the setting data,
• Input/change the zero offset,
• Input the user data.
The setup functions are collected together in the operating area
Parameters. To get to this area, click on:
Para-
meter
• the operating area button,
• the Parameter softkey.
When you select this operating area for the first time the Parameters
Operating Area working window appears. When you subsequently
change into this operating area the last selected working window will
appear.
The following operating areas are available via the softkeys:
• Tool offsets
• R parameters
• Setting data
• Zero offset
• User data
Press the desired softkey to activate one of the functions described
below.
Siemens AG, 2004. All rights reserved.
3-30 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
