Machine Data, NC Start-Up, System Parameters – Operating Area Start-Up 03.04
10.3 NC startu
10
10.3 NC startup
Function
The NC startup offers the following function:
• NCK address
Precondition
The NC softkey in the Startup Overview working window has been
pressed.
The following working window is then displayed:
NC Startup Overview working window
Operating sequence
Call up the desired function with the corresponding softkey.
NCK addr. NCK Address working window
10.3.1 NCK address
Function
With this function you can assign a new address to the NCK.
Precondition
• The NCK addr.softkey has been pressed in the NC Startup
Overview working window.
Siemens AG, 2004. All rights reserved.
10-124 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
