10
03.04 Machine Data, NC Start-Up, System Parameters – Operating Area Start-Up
10.3 NC startu
10
The following working window is then displayed:
NCK Address working window
Operating sequence
• Write a new NCK address into the input field,
• Click on OK to save it just for the current session, or
• Click on Save to save it permanently.
There is a safety prompt before saving:
Attention!
Do you want to change the NCK address?
The changes will not become effective until an NCK power on reset
has been performed.
Close this prompt by clicking either Cancel or OK.
Further buttons
Cancel, Returns to the calling working window without
Recall changing the NCK address.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 10-125
