6
Automatic Mode – Operating Area Machine 03.04
6.2 Pro
ram blocks
6
Operating sequence
• Enter the command alphanumerically.
or
• Transfer the command into the buffer memory with the Enter key
or
• by moving to a different line with one of the cursor keys.
Softkeys
Delete all Deletes the overstore buffer.
Further buttons
Start Executes the entered commands and returns to the
calling working window.
Recall Returns to the calling working window without
executing the commands.
6.2.6 Program control
Function
The program operation mode can be changed using this function. The
following program controls can be activated or deactivated:
SKP Skip block
DRY Dry run feed
ROV Rapid traverse override
M01 Programmed stop
DRF Selection of DRF offset
PRT Program test
SBL1 Stop after every machine function block
SBL2 Stop after every block
Siemens AG, 2004. All rights reserved.
6-76 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
