4
Program operating area 03.04
4.1 Directories
4
Operating sequence
• Use the Select button to determine the file type
• Type in the new name.
• Click on the softkey OK to create a new file.
This file is empty, and you can use the Editor to write in it.
Further buttons
Abort (Softkey) or
Recall Exit the working window without
creating a file.
4.1.4 Parts programs/subroutines
Function
The Program main screen contains a complete overview of all parts
programs and subroutines.
Precondition
In the Standard Directories Overview working window one of the
following softkeys has been selected:
MPF for global parts programs or, analogously,
SPF for global subroutines.
Operating sequence
• Use the corresponding softkey to activate one of the following
functions:
New An additional Create New File working window opens in the
lower half of the screen:
Siemens AG, 2004. All rights reserved.
4-50 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
