03.04 Automatic Mode – Operating Area Machine
6.2 Pro
ram blocks
6
Softkeys
Channel Switches to the next channel (only displayed if two or
more channels are present)
Please read the warning below!
Actual values MCS/WCS actual values
If the machine function "Reposition" is active then the
REPOS displacement is displayed, otherwise the
distance-to-go is shown.
Curr.block Current block
Search Block search
Progr.level Program levels
Progr.corr Program correction
> 2nd softkey level (toggle button)
Overstore Correction block overstore
Progr.ctrl Program control
Warning
When the channel is switched over, one of the following may occur
depending on the PLC programming:
• The position of the override rotary switch may no longer match
the override on the channel (e.g. when the rotary switch only acts
on channel 1) or
• The override on the channel may change when the channel is
switched over.
Machine manufacturer
The manufacturer of the installation must ensure that the installation is
configured in a way which prevents dangerous situations from arising.
Siemens AG, 2004. All rights reserved.
SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition 6-71
