5
Manual Mode – Operating Area Machine 03.04
5.6 MDA o
eratin
mode
5
Siemens AG, 2004. All rights reserved.
5-68 SINUMERIK 840D/840Di/810D Operator's Guide Handheld Terminal 6 (BAH) - 03.04 Edition
Softkeys
Actual values Actual value display, depending on the selected
coordinate system
Progr.Ctrl Program control
Delete MDA Deletes the MDA program (without safety prompt)
Save MDA Saves the MDA program.
The following working window appears when this softkey is pressed:
Save MDA program
Save MDA Program working window
Operating sequence
• Type in the program name.
• Click on the OK softkey to save the MDA program and return to
the previously active working window.
Further buttons
Recall or Returns to the previously active working
window
Cancel softkey To cancel without accepting the value.
