1PosInc/Analog
4.6 Functions of the 1PosInc/Analog
ET 200S Positioning
Operating Instructions, 05/2007, A5E00124871-04
175
Causes of Errors for JOB_ERR
Table 4-5 Causes of Errors for JOB_ERR
Error Number Meaning Remedy
21 JOB unknown Permissible JOBs are:
• JOB 0
• JOB 1
• JOB 3
• JOB 4
• JOB 9
• JOB 10
• JOB 11
• JOB 15
23 ERR_ENCODER is displayed Check the encoder wiring
30 Evaluating the Reference Signal: Reference point
coordinates ≥ end of rotary axis
34 Setting an Actual Value: actual value coordinates
≥ end of rotary axis
35 Display current values: Selection unknown
36 Latch Function: Edge selection unknown
37 Display current values: JOB 15 cannot be
activated with the latch function running.
38 Monitoring of the direction of rotation
Path difference > 65 535
40 Voltage setting
Rapid feed speed > 32 511
41 Voltage setting creep feed speed > 32 511
42 Changing the acceleration T
acc
> 65 535
43 Deceleration T
dec
> 65 535
