7.6.9 Canceling JOB Processing (JOB 0)
Definition
If you activate JOB 0, the 1PosU responds as follows:
● It cancels the current JOB 9 (reference signal evaluation)
● It cancels the current JOB 10 (latch function)
● It sets a pending JOB_ERR = 0.
You can activate JOB 0 whatever the state of the axis.
Effect on the MODEs
MODEs are not affected by JOB 0.
Control Signals: Canceling JOB processing
Address Assignment
Bits 4.7 to 4.4 :
7 6 5 4 Bit
0 0 0 0
JOB 0 = Cancel JOB processing
Byte 4
Bit 0: JOB_REQ
Feedback Signals: Canceling JOB processing
Address Assignment
Byte 4 Bit 1: JOB_ERR
Bit 0: JOB_ACK
