Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

8 Using the Data Record Interface
136
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
Flag 1 Flag 2
Bit Number Meaning Bit Number Meaning
0 CONFIG_OK 0 PERIPHERY_OK
1 LDS_0 1 DATA_EXCHANGE_ACTIVE
2 AUTO_ADDR_ASSIGN 2 OFFLINE
3 AUTO_ADDR_AVAIL 3 AUTO_ADDR_ENABLE
4 CONFIG_MODE 4 Ground short
5 NORMAL_MODE 5 EPROM_OK
6 APF 6 reserved
7 OFFLINE_READY 7 reserved
The meaning of the flags is the same as in the “Get_LPS_LAS_LDS_LPF_Flags”
job, Section 8.2.1.4).
