Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

4 Keypad and Display
45
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
“IND. ETHERNET” menu
IND. ETHERNET > Info > Ethernet Port 1 >
Link (physical connection up/down)
Mode (10/100 Mbps, half duplex/full duplex)
Input bytes (number of received bytes)
Output bytes (number of sent bytes)
> Ethernet Port 2 ... (as for Port 1)
IND. ETHERNET > IP Parameters > DHCP >
disabled
MAC address
Device Name
Client ID
Change Client ID
IP > Set IP address
Mask > Set subnet mask
GW > Set gateway
IND. ETHERNET > MAC address > display MAC address
“PROFINET IO” menu
PROFINET > Info > Device name > Change PROFINET device name
IP address Controller
Controller name (PROFINET device name of controller)
Connection (AR status online/offline)
Controller (Controller status RUN/STOP)
Update time [ms]
PROFINET > Error
