Siemens SIMATIC NET IE/AS-INTERFACE LINK PN IO User Manual

4 Keypad and Display
47
IE/AS−INTERFACE LINK PN IO as of hardware version 1, as of firmware version V2.0
Release 08/2018
C79000−G8976−C216−03
AS-i Line 1 > Slave Info >
Config. > Change configuration
Parameter > Change parameters
Bin. I/O > Change binary Inputs/outputs
Analog > Change analog inputs/outputs
Status
Statistics > Reset all counters
Slave Failure
Missing frames
Bad frame
Statistics > Reset all counters
I/O Error
Protocol Error
Bad master frame
String transfer > Write (string transfer to slave)
AS-i Line 1 > Change addr. > Change slave address
AS-i Line 1 > Change ID1 > Set ID1 (only for slave “0”)
AS-i Line 1 > Act −> Conf > Adopt Act −> Conf
AS-i Line 1 > Address help > enable/disable
SYSTEM > AS-i Line 2 ...: Structure and use as with AS-i Line 1
With a single master, only “AS-i line” is displayed.
-
