Siemens SINUMERIK 802D sl Instruction Manual

Commissioning
9.10 Start-up sequence when working with STARTER
9-109
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
9.10 Start-up sequence when working with STARTER
STARTER provides two alternative procedures for creating a drive object:
S OFFLINE, where you can create and parameterize your drive unit configuration using a
wizard;
S ONLINE, where you load an existing configuration and parameterization of a drive unit
into STARTER using the wizard.
If you have created or loaded a project in STARTER, you can operate the drive using the
control panel of STARTER.
9.10.1 Creating a drive object OFFLINE
The following steps are required to create a drive object OFFLINE:
Table 9-13 OFFLINE
Step Procedure Section
1 Start the STARTER commissioning tool and use the STARTER project
Wizard to create a new project.
10.1.1
2 Set up the PPI interface. 10.1.1
3 Insert the drive unit. 10.1.1
4 Use the Wizard to configure the drive unit with, for example, the infeed,
drive properties, drive with power section, motor, encoder, and so on.
10.1.2
5 Save your project. 10.1.2
6 Continue with “Operating the STARTER control panel (motor rotating)”. 10.2
