Siemens SINUMERIK 802D sl Instruction Manual

Commissioning
9.11 Diagnosis via STARTER
9-111
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
9.11 Diagnosis via STARTER
Description
The diagnostic functions support commissioning and service personnel during commissio-
ning, troubleshooting, diagnostics and service activities.
General
Prerequisites: STARTER is in the online mode.
STARTER provides the following diagnostic functions:
S PROFIBUS diagnostic buffer
The message output window shows the states of the control/status words, parameters
and drive enable signals for the selected drive/device.
S Fault/alarm display in the alarms output window
Faults and warnings can be displayed either for one or for several drives/units. The fault/
alarm description is called up by selecting “Help –> Context” or by pressing the SHIFT
+ F1 keys.
S Diagnostic overview
An overview table of all drives existing in the project is displayed.
– Device: The existing devices and drives are displayed with their names; the device
status is displayed in the “Device diagnosis” window.
– Operating status: The operating status (e.g. OFFLINE, ONLINE, STARTUP, STOP,
STOP U, RUN) of the device or of the drive is displayed; it can be controlled via the
mode selector switch.
S Signals specified from the function generator (see Section 9.11.1)
S Signal recording using the Trace function (see Section 9.11.2)
S Analysis of the control behavior using the measuring function (see Section 9.11.3)
S Output of voltage signals for external measuring instruments via measuring sockets (see
Section 9.11.4)
