9.10 Start-up sequence when working with STARTER
Commissioning
9-110
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
9.10.2 Operating the STARTER control panel (motor rotating)
The following steps are required to operate the control panel of STARTER so that the motor
rotates:
Table 9-14 Motor rotates
Step Procedure Section
1 Open the project. 10.2.1
2 Establish a connection to the target system.
Switch to ONLINE mode.
10.2.1
3 Load the project into the drive unit. When doing so, observe the LEDs on the
control unit; these indicate when the project has been loaded completely.
10.2.1
4 Save the parameters in the drive unit with RAM to ROM. 10.2.1
5 Operate the STARTER control panel; the motor will rotate. 10.2.2
9.10.3 Creating a drive project ONLINE (recommended)
The following steps are required to create a drive object ONLINE:
Table 9-15 ONLINE
Step Procedure Section
1 Start the STARTER commissioning tool. 10.3.1
2 Create a new project. 10.3.1
3 Set up the PROFIBUS interface. 10.3.1
4 Search ONLINE for the stations (drive units) which can be reached.
The drive project will be inserted into the project.
10.3.1
5 Configure and acquire the topology and configuration of the drive unit
automatically.
10.3.2
6 Configure the motor and check the acquired topology. 10.3.3
7 Save your project. 10.3.3
8 Continue with “Operating the STARTER control panel (motor rotating)”. 10.2
