Installation
6-50
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
Mounting the CNC operator panel (PCU)
Install the CNC operator panel as shown on the relevant illustrations and diagrams 5-1
and 5-2.
!
Caution
If you do not have access from the rear during installation, you must connect the CNC
operator panel prior to its installation. When doing so, note that connector X40 (powersupply
connection) and the lines connected to it protrude beyond the mounting edge.
When installing the CNC operator panel, do not pull off the connector; otherwise, the
cables could be damaged!
Installing the machine control panel
Install the CNC operator panel as shown on the relevant illustrations and diagrams 5-3
and 5-4.
Installing the CNC full keyboard
You can install the CNC full keyboard either next to the operator panel or beneath the CNC
operator panel. Observe the specifications in Figs. 5-5 through 5-8.
Installing the PP72/48 I/O module
This module must be installed according to EN 60204. For the dimension drawing of the
module, see Fig. 5-9.
Installing the SINAMICS S120 drive
For information regarding the SINAMICS S120 drive system (design, connection, planning,
dimensioning, configuring, etc.), see:
References: /GH1/, /GH2/, Equipment Manuals
