Siemens SINUMERIK 802D sl Instruction Manual

Connecting
7.16 Connecting the machine control panel to the PP72/48 I/O module
7-73
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
7.16 Connecting the machine control panel to the PP72/48 I/O module
To connect the machine control panel (X1201 and X1202) to the PP72/48 I/O module (e.g. X222
and X333)
, use two ribbon cables.
For more information, please refer to:
References: /BU/, Catalog
Note
More information regarding the machine control panel and the pin assignment of the
connectors X1201 and X1202 is to be found on the installed toolbox at:
Start > Programs > Toolbox802sl > PLC802slLibrary > Description.
