B.1 Electromagnetic compatibility
Standards and Approvals
B-232
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
B.1 Electromagnetic compatibility
Definition
Electromagnetic compatibility is the ability of equipment or systems to be used in their inten-
ded environment within designed efficiency levels without causing or receiving degradation
due to unintentional electromagnetic interference.
The D4xx also satisfies the requirements of the EMC regulations of the internal European
market.
Information on interference immunity and EMC conformance are provided in the following.
Pulse-shaped interference
The table below illustrates the electromagnetic compatibility of modules when exposed to
fast transients.
Fast transient Tested with Corresponds to the
degree of severity
Electrostatic discharge
tested in accordance with DIN EN 61000-4-2
8 kV
4 kV
3 (air discharge)
2 (contact discharge)
Burst pulses (fast transient interference)
complying to DIN 61000-4-4
2 kV (supply cable)
1 kV (signal cable)
3
Surge
complying to DIN EN 61000-4-5
S Asymmetric coupling
S Symmetric coupling
0.5 kV (supply line)
1 kV (signal line/data line)
0.5 kV (supply line)
1
2
1
