Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-201
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
379 SPINDLE_DISP_MODE
decimal
0: Standard mode, display of spindle speed
1: Constant cutting rate, display with G96 set
2: Mixed display
immediately 3/3
0 0 0 2 Byte
A.1.2 General machine data
MD
number
MD identifier
Unit Brief description Activation
Display filter Attributes Data type
Default Dimension Default value Minimum value Maximum value Protection
System * Dimension Default value Minimum value Maximum value Protection
* Values other than those in the standard system
Note regarding the value definition:
TRUE corresponds to 1
FALSE corresponds to 0
10000 AXCONF_MACHAX_NAME_TAB
– Machine axis name POWER ON
N01, N11 – STRING
Default 6 “X1”, “Y1”, “Z1”, “SP”,
“A1”, “PLCX1”
– – 2/2
10008 MAXNUM_PLC_CTRL_AXES
– Max. no. PLC-controlled axes POWER ON
N01, N09 – BYTE
Default – 0 0 1 2/2
10074 PLC_IPO_TIME_RATIO
– Factor of the PLC task for main run POWER ON
N01, N05 – DWORD
Default – 1 1 50 2/2
10088 REBOOT_DELAY_TIME
s Reboot delay IMMED.
EXP – DOUBLE
Default – 0.2 0.0 1.0 2/2
10200 INT_INCR_PER_MM
– Computational resolution for linear positions POWER ON
N01 – DOUBLE
Default – 1000.0 1.0 1.0e9 2/2
10210 INT_INCR_PER_DEG
– Computational resolution for angular positions POWER ON
N01 – DOUBLE
Default – 1000.0 1.0 1.0e9 2/2
10240 SCALING_SYSTEM_IS_METRIC
– Metric basic system POWER ON
N01 SCAL BOOLEAN
Default – TRUE – – 2/2
10710 PROG_SD_RESET_SAVE_TAB
– Setting data to be updated POWER ON
EXP, N01 – DWORD
Default 30 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0
– – 2/2
