A.1 List of machine data
Machine and Setting Data 802D
A-206
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
18050 INFO_FREE_MEM_DYNAMIC
– Free unbuffered memory [bytes] POWER ON
N01, N02, N05 READ DWORD
Default – 430080 – – 7/2
plus – 1048576 – – 7/2
18060 INFO_FREE_MEM_STATIC
– Free buffered memory [bytes] POWER ON
N01, N02, N05 READ DWORD
Default – 262144 – – 7/2
plus – – – 7/2
18080 MM_TOOL_MANAGEMENT_MASK
– Reserved memory for the tool management (SRAM) POWER ON
N02, N09 – DWORD
Default – 0x0 0 0xFFFF 2/2
18102 MM_TYPE_OF_CUTTING_EDGE
– Type of D number programming (SRAM) POWER ON
N02, N09 – DWORD
Default – 0 0 1 2/2
18120 MM_NUM_GUD_NAMES_NCK
– Number of global GUD definitions (SRAM) POWER ON
N02 – DWORD
Default – 50 – – 2/2
18130 MM_NUM_GUD_NAMES_CHAN
– Number of channel GUD definitions (SRAM) POWER ON
N02 – DWORD
Default – 100 – – 2/2
18150 MM_GUD_VALUES_MEM
– Memory space for GUD values (SRAM) POWER ON
N02 – DWORD
Default – 32 – – 2/2
A.1.3 Channelspecific machine data
MD
number
MD identifier
Unit Brief description Activation
Display filter Attributes Data type
Default Dimension Default value Minimum value Maximum value Protection
System * Dimension Default value Minimum value Maximum value Protection
* Values other than those in the standard system
Note regarding the value definition:
TRUE corresponds to 1
FALSE corresponds to 0
20050 AXCONF_GEOAX_ASSIGN_TAB
– Assignment ‘geometry/channel axis’ POWER ON
C01, C10 – BYTE
Default 3 1, 2, 3 0 6 2/2
20070 AXCONF_MACHAX_USED
– Machine axis number valid in channel POWER ON
C01, C10 – BYTE
Default 6 1, 2, 3, 4, 5, 0, 0 6 2/2
