Siemens SINUMERIK 802D sl Instruction Manual

Machine and Setting Data 802D
A.1 List of machine data
A-205
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
13070 DRIVE_FUNCTION_MASK
– Used DP functions POWER ON
N04, N10 – DWORD
Default 31 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0
– – 2/2
13080 DRIVE_TYPE_DP
– Drive type with Profibus POWER ON
EXP – BYTE
Default 31 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0
0 4 2/2
13200 MEAS_PROBE_LOW_ACTIVE
– Polarity change of the probe POWER ON
N10, N09 – BOOLEAN
Default 2 FALSE, FALSE – – 3/3
13220 MEAS_PROBE_DELAY_TIME
s Detection of probe deflection delay time POWER ON
N10, N09 – DOUBLE
Default 2 0.0, 0.0 0 0.1 3/3
14510 USER_DATA_INT
– User data (INT) POWER ON
N03 – DWORD
Default 32 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0
–32768 32767 7/3
14512 USER_DATA_HEX
– User data (HEX) POWER ON
N03 – DWORD
Default 32 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0, 0, 0, 0
0 0x0FF 7/3
14514 USER_DATA_FLOAT
– User data (FLOAT) POWER ON
N03 – DOUBLE
Default 8 0.0, 0.0, 0.0, 0.0, 0.0, 0.0,
0.0, 0.0
–3.40e38 3.40e38 7/3
14516 USER_DATA_PLC_ALARM
– User data (HEX) POWER ON
N03 – BYTE
Default 64 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,
0, 0, 0, 0, 0, 0, 0…
– – 7/3
17530 TOOL_DATA_CHANGE_COUNTER
– Mark tool data change for HMI POWER ON
EXP, N01 – DWORD
Default – 0 0 0xF 2/2
18040 VERSION_INFO
– Version and (if necessary) date of PCMCIA card POWER ON
N05 READ STRING
Default 4 – – 7/2
plus – “802D–TM2” – – 2/2
