Siemens SINUMERIK 802D sl Instruction Manual

Connecting
7.6 Connecting the MCPA module
7-59
SINUMERIK 802D sl Instruction Manual (BA), 05/2005 Edition
6FC5 397-0CP10-1BA0
7.6 Connecting the MCPA module
The MCPA module is connected to the PCU via X110. The new machine control panel
(MCP) is connected using the supplied ribbon cable. X1 is connected to X1201, and X2 to
X1202 (see Fig. 7-3).
The power supply to the MCPA module is provided via connector X1021
(PIN1 24 V; PIN10 0 V).
Note
The variable assignment of the machine control panel is described in the PLC user interface
(please refer to: Description of Functions 802Dsl).
See also: PLC subroutine library V01.07.00 of SINUMERIK 802D sl.
